*BY PURCHASING THIS HIGH PERFORMANCE PRODUCT YOU AGREE TO THE TERMS AND CONDITIONS SET FORTH IN THE LIMITED WARRANTY EXCLUSION POLICY
Just when you thought that it was too complicated to properly power up megawatt subwoofers; Massive Audio comes along and releases the DP10K Power Amp!
All Digital, Ultra High-Speed Switching, Crystal Clean Full Range with a TRUE power output of 5,600 Watts RMS @ 1 ohm @ 16V.
This amplifier measures in at only 3.07” x 9.11” x 13.07” and packs twin full time exhaust fans to cool its output. The DP10K can do all this and operate at DC 9V—16V. Protection is key and is controlled by a processor that illuminates a red LED when 85% of the amplifier’s capacity limit is reached. Adjustable Hi Pass and Low Pass crossovers along with a parametric equalizer with a variable 0-12dB bass boost allow for complete control.
- Up to 5,600 Watts of RMS power @ 16 Volts
- 1 Ohm Stable
- 16V Max Input
- Low, High, Band Pass Filters
- Parametric EQ
- Subsonic Filter Fixed @ 10Hz
- Dual Cooling Fans
- 6 Way Protection with Clip Capacity Limiter LED’s
- 4 Ohm—2,200 Watts
- 2 Ohm—3,300 Watts
- 1 Ohm—5,300 Watts
- 1 Ohm (@16V) —5,600 Watts
RMS @ 1 Ohm 14.4V | 5,300w x 1 |
PEAK Power | 10,000w x 1 |
RMS @ 2 Ohm 14.4V | 3,300w x 1 |
Bridged RMS | n/a |
Min Impedance | 1 Ohm |
Min Ohm Bridged | n/a |
THD | 0.9% Continuous @ 4Ohm, 100Hz |
S/N | >90 dB |
Max Voltage | 16v |
Max RCA Voltage | 10v (+/- 5%) |
Freq. Response | 10Hz ~ 12KHz (+/-1dB) |
Dimensions | 9.11 (in) W x 3.07 (in) H x 13.07 (in) L |
Bass Remote | N/A |
